UT71A- Intelligent Digital Multimeter

UNI-T UT71A

• SPECIAL FUNCTIONS:
• Fused 10A range
• Current measurement alarm
• Function Set Up
• Auto ranging
• Voltage/Current AC+DC measurement
• Diode
• Continuity buzzer
• True RMS
• Peak Hold
• Max/Min mode
• Relative mode
• Data Hold
• USB
• Full icon display
• Sleep mode
• Low battery display
• Input impedance for DC or AC Voltage: 2.5 GOhm (for 200mV), 10 MOhm (for all other ranges)
• Double display backlight
• Max. display 20000 (73 x 50mm)
• Analogue bar graph

SPECIFICATION:
DC voltage: 200mV / 2V / 20V / 200V / 1000V
- best accuracy: +/- (0.1%+8)
AC voltage: 2V / 20V / 200V / 1000V
- best accuracy: +/- (0.8%+40)
DC current: 200µA / 2000µA / 20mA / 200mA / 10A
- best accuracy: +/- (0.2%+15)
AC current: 200µA / 2000µA / 20mA / 200mA / 10A
- best accuracy: +/- (1%+15)
Resistance: 200 Ohm / 2 kOhm / 20 kOhm / 200 kOhm / 2 MOhm / 20 MOhm
- best accuracy: +/- (0.5%+20)
Capacitance: 20nF / 200nF / 2µF / 20µF / 200µF / 2mF / 20mF
- best accuracy: +/- (1.5%+20)
Frequency: 20Hz / 200Hz / 2kHz / 20kHz / 200kHz / 2MHz / 20MHz / 200MHz
- best accuracy: +/- (0.1%+15)
Duty cycle: 10 ~ 90%
- best accuracy: +/- (1%+30)


GENERAL CHARACTERISTICS:
Power: 9V bat. (6F22)
Product size: 200 x 93 x 40mm
Product weight: 384g
